Image Sensor

1/2.7" Progressive Scan CMOS

Effective Pixels

5 Megapixel

Maximum Resolution

2592 × 1944

Video Compression

H.265+, H.265, H.264+, H.264

Frame Rate

Up to 25/30fps

Lens Type

Fixed Fisheye Lens

Lens Size

1.8mm

Viewing Angle

180° Panoramic

Minimum Illumination

Color: 0.01Lux, B/W: 0Lux (IR ON)

Day/Night

Automatic IR Cut Filter

Infrared Distance

Up to 20m

IR LEDs

STARLIGHT

Digital Zoom

16×

Electronic PTZ

Supported

Dewarp Function

Supported

Audio

Built-in Microphone

Audio Compression

G.711A / G.711U / AAC

Motion Detection

Yes

Human Detection

Optional

Intrusion Detection

Supported

Line Crossing

N/A

Privacy Mask

N/A

Image Enhancement

BLC, HLC, 3D DNR

White Balance

Auto / Manual

Defog

Supported

Ethernet

RJ45 10/100 Mbps

ONVIF

Profile S

RTSP

Supported

Mobile App

Android / iOS

Web Browser

IE, Edge, Chrome

SD Card

N/A

Power Supply

DC12V ±10%

PoE

IEEE802.3af (Optional)

Power Consumption

<8W

Operating Temperature

−20°C to +60°C

Humidity

≤95% RH

Protection

IP66 (Outdoor Model)

Housing Material

Plastic
